185MM 1FZ S P2

Technical Parameters

Product Advantage

• Twin Plate Design, Double the Holding Power

Two 185 mm friction discs working around a billet floater plate nearly double friction surface versus a single-disc upgrade. Capacity is rated for serious 1FZ-FE builds, reliably supporting output well past 600 hp​ on supercharged and turbocharged conversions. Two plates also share the clamp load, so pedal effort stays moderate — strong enough for heavy loads, manageable enough for daily driving.

• Damping Springs Protect Your Driveline

Each disc is built with spring​ damping — internal springs cushion torque spikes before they reach the input shaft. Boosted torque delivery, low-range gearing and sudden traction changes all generate violent shock loads that a rigid race disc transmits straight into the gearbox, destroying synchromesh and axles. The damping springs absorb those shocks, cutting idle gear rattle and judder when pulling away.

• Built for Sustained Load and Heat

Land Cruisers work hard: steep climbs, deep sand, heavy towing, long hours at low speed under high torque. This 185mm racing clutch kit​ is engineered for exactly that duty cycle. Billet aluminum draws heat away from the friction faces far faster than a stamped steel cover, resisting fade through repeated heavy launches and sustained load, while two friction surfaces share the thermal load.

• Compact Size, Low Rotating Inertia

Holding diameter to 185 mm keeps rotating mass concentrated near the crankshaft centreline, so the engine revs freely and the driveline responds quickly. Low inertia helps the engine recover between shifts and reduces stress during sudden load changes — a genuine advantage in technical terrain where quick throttle corrections and precise clutch modulation keep you moving instead of stalling.

• Cerametallic Friction, Rebuildable by Design

Each disc uses a sintered cerametallic friction face developed for competition. It keeps biting at temperatures that would destroy an organic disc, and delivers controllable, progressive modulation rather than an unpredictable on/off switch. Discs, floater plate and drive components are individually replaceable, so a rebuild costs a fraction of a complete kit. Every unit is CNC-machined under tight tolerance, dynamically balanced and serialised.

• Quieter and Smoother Than a Triple Plate

With only one floater plate and two discs, this kit runs noticeably quieter and engages more smoothly than a triple plate, while the spring damping further isolates driveline vibration. For vehicles that spend most of their time on the road or on long expeditions, that refinement is worth more than capacity you will never use. Direct bolt-on to H150F / H151F — no machining, no adapter plate.

Product Uses

• High-Output Supercharged and Turbocharged Builds

A boosted 1FZ-FE produces torque the factory clutch was never designed to hold, especially in low range where gearing multiplies the load enormously. This 7.25" twin plate race clutch​ handles output well past 600 hp​ without slipping, and the discs with spring​ damping cushion the violent torque spikes boosted engines deliver. Boost, larger tyres and heavy loads stop being limited by the clutch.

• Rock Crawling and Technical Off-Road

Crawling demands constant clutch slipping, precise modulation and repeated heat cycles at low speed, conditions that glaze and overheat a standard clutch. The cerametallic faces and billet aluminum manage heat far better, while progressive engagement lets you feather the clutch with control. The spring damping​ protects the driveline when grip returns suddenly and the whole drivetrain takes a shock load.

• Desert Racing and High-Speed Off-Road

Sustained high-speed running through sand and whoops generates continuous heat and driveline shock. This 185mm racing clutch kit​ sheds heat efficiently and holds capacity through long, punishing sections. Consistent pedal feel means predictable shifts when terrain changes suddenly, and discs can be refreshed between stages rather than replacing the whole assembly — a real advantage during multi-day events.

• Heavy Towing and Expedition Use

Loaded expedition Cruisers and tow rigs place sustained torque through the clutch for hours at a time. The twin plate layout spreads that load across two friction surfaces, dramatically reducing wear and heat build-up compared with a single disc. Discs built with spring​ damping isolate vibration during long highway stretches, making the vehicle quieter and more relaxed on the road.

• Overland and Daily-Driven Builds

This is where a twin plate with spring genuinely beats a triple plate. Pedal effort stays moderate in traffic, idle rattle is minimal, and pulling away from a standstill is smooth rather than snatchy. For a Cruiser that tows during the week and hits the trails at the weekend, this kit delivers the capacity you need without punishing you the rest of the time.

• Engine Conversions and Drivetrain Upgrades

Swapping a 1FZ-FE into another chassis, or upgrading to a stronger manual gearbox, usually leaves the original clutch mismatched to the new combination. This kit bolts directly to H150F / H151F five-speed manuals without custom machining or adapter plates, and the discs with spring​ damping isolate vibration between engine and transmission — ideal for conversions where torsional characteristics were never originally matched.
